QUAD Vena II Play User Manual

26
SPECIFICATIONS
Vena II Play
Dual - band 802.11a/b/g/n
Support global, popular streaming content（Amazon Music, Spotify, TIDAL,
Juke, BBC, ESPN, KKBox, SiriusXM, Napster, Internet Radio, Deezer,
iHeartRadio, PANDORA, SOUNDMACHINE, tunein, Qobuz, Qmusic）
Support Speakers Group
Support android/iOS/Kindle Fire/Windows PC
525mV
2.5mV
10Kohm (AUX) , 47Kohm // 100pF (Phono)
2 x AUX , 1x Phono (MM)
1 x Pre-Out (RCA)
20Hz-20KHz (+/- 0.5dB)
< 0.002%
> 110dB (A-Weighted)
2 x 45W (8ohm) / 2 x 65W (4ohm)
20Hz-20KHz (+/- 0.5dB)
< 0.005% (30W, 8ohm)
> 108dB (A-Weighted)
ESS Sabre32 ES9018K2M chip
Optical, coaxial: 44.1kHz ---192kHz ;
USB:44.1kHz---384kHz(PCM)/DSD64, DSD128, DSD256
Ethernet, Wi-Fi: 44.1kHz ---192kHz
1 x Coaxial, 1 x Toslink Optical
1 x USB for PC USB
Bluetooth(aptX, aptX LL)
301 x 95 x 313 mm
6.1kg
Model
DTS Play-Fi Technology
Analogue Pre-Amplifier Section:
Input Sensitivity (AUX)
Input Sensitivity (Phono, MM)
Input Impedance
Inputs
Output
Frequency Response
Total Harmonic Distortion (THD)
Signal To Noise
Power Amplifier Section
Rated Power
Frequency Response
Total Harmonic Distortion (THD)
Signal To Noise
Digital Section
DAC
Sampling Frequency
Digital Input
Mechanical Section
Size (W X H X D)
Net Weight
Channel Indicators
The channel indicators indicate the current state of the channel you choose.
Device States
Wi-Fi mode in initialization state
WPS network set-up mode
Standard network setup mode
Connecting network
Wi-Fi /Wired Network connection
Spotify
BT disconnection
BT connection
In the PC USB channel
In the OPT channel
In the COAX channel
In the AUX1 channel
In the AUX2 channel
In the PHONO channel
Channel Indicators
NET Indicator
BT Indicator
USB Indicator
OPT Indicator
COAX Indicator
AUX1 Indicator
AUX2 Indicator
PHONO Indicator
LED States
LED is fast-flash white
LED is double-flash white
LED breathe white
LED slow-flash white
LED is bright white
LED is bright green
LED flash white
LED is bright white
LED is bright white
LED is bright white
LED is bright white
LED is bright white
LED is bright white
LED is bright white

QUAD Vena II Play Specifications

General

Power Output	45W per channel (8Ω)
Frequency Response	20Hz-20kHz (±0.5dB)
DAC	ESS Sabre32 ES9018K2M
Damping Factor	>100
Inputs	2 x Optical, 1 x Coaxial, 1 x USB, Ethernet
Outputs	Speaker terminals, 1 x Pre-out
Bluetooth	Yes (aptX HD)
Signal-to-Noise Ratio	>108dB (A-weighted)
Power Consumption	300W
