Quadra-Fire 3100 Series Operating & Maintenance Instructions

Page 25
250-6103C December 6, 2004
3100 ACT Wood Stove Series
R
831-1671 . . . . . . . .Ash Removal System (ARS)
831-1701 . . . . . . . .Blower Assembly
832-1092 . . . . . . . .Door Assembly, Black
832-1912 . . . . . . . .Door Assembly, Gold Trim
DR-31/43NL . . . . . .Door Assembly, Nickel Trim
UK-DRNL . . . . . . . .Nickel Upgrade Kit, (includes (2) hinge pins & (3) spring handles)
831-1250 . . . . . . . .Queen Anne Legs, Gold
831-1240 . . . . . . . .Queen Anne Legs, Black
831-1780 . . . . . . . .Outside Air Kit, Pedestal or Leg, Floor or Rear
831-1860 . . . . . . . .Pedestal Assembly
831-0972 . . . . . . . .Top Heat Shield, Black (to reduce rear clearances) 3100 Millennium only
831-1650 . . . . . . . .Top Heat Shield, Gold Grille Accessory
831-1800 . . . . . . . Baffle, Fiberboard
831-1820 . . . . . . . Brick Set, ARS Step Top Model
831-1830 . . . . . . . Brick Set, Millennium Model
832-0550 . . . . . . . Brick, Individual, (give dimensions needed, see page 21)
832-3401 . . . . . . . Ceramic Blanket, 1” thick (field cut to fit size 14-1/4” x 19-1/2”)
832-2670 . . . . . . . Component Pack (includes paint, pedestal oak trim, gold spring handles and manual)
832-0540 . . . . . . . Door Handle Assembly
832-1680 . . . . . . . Door Rope, field cut to proper length
832-0060 . . . . . . . Glass Assembly
831-1810 . . . . . . . Manifold tubes, set of 4
832-0620 . . . . . . . Spring Handle, Door, 1/2”, Gold
832-0630 . . . . . . . Spring Handle, Air Control, 1/4”, Gold
3100 Millennium
3100 Step Top Uni-body
820-0670 3100 Millennium, Black Door, Pedestal
31M-GT 3100 Millennium, Gold Trim Door, Pedestal
31M-NT 3100 Millennium, Nickel Trim Door, Pedestal
820-0691 3100 Step Top, Uni-Body
Door Options
832-1092 Black Door
832-1912 Gold Trim Door
DR-31/43NL Nickel Trim Door
Base Options
831-1860 Pedestal
831-1250 Queen Anne Legs, Gold
831-1240 Queen Anne Legs, Black
QANL Queen Anne Legs, Nickel
ACCESSORIES
SERVICE PARTS
APPLIANCES
NOTE: Ash Removal System is not avail-
able for the Millennium Model

Quadra-Fire 3100 Series Specifications

General

EPA Certified	Yes
Flue Size	6 inches
Efficiency	78%
Firebox Size	2.0 cu ft
Log Length	18 inches
Depth	26.5 inches
Maximum Burn Time	10 hours
