Quadra-Fire 3100 Series Operating & Maintenance Instructions

Page 5
250-6103C December 6, 2004
3100 ACT Wood Stove Series
R
DIMENSIONS
24-5/8" (625mm)
33-3/8"
(625mm)
10-1/2"
(267mm)
15-15/16" (389mm)
4-1/2" (114mm)
25-5/32" (639mm)
3100 STEP TOP UNI-BODY PEDESTAL MODEL
3100 STEP TOP UNI-BODY LEG MODEL
C
L
24-5/8" (625mm)
9-1/4"
(235mm)
12-5/16"
(313mm)
15-1/16" (383mm)
14-15/16"
(379mm)
10-15/16"
(278mm)
19-1/16" (484mm)
18-1/4" (464mm
)
21.0" (533mm)
34-1/16"
(357mm)
Back of stove to glass
10-1/2"
(267mm)
20-1/4" (514mm)
16-1/8"
(556mm)
21-7/8" (556mm)
13-1/2" (343mm)
26-1/8" (664mm)
23-1/2" (597mm)
20-1/2" (521mm)
8-1/2"
(216mm)
29.0"
(737mm)
4-5/16"
(110mm)
C
L
2-3/8"
(60mm)
5-9/16"
(141mm)
SERIAL NUMBER LABEL LOCATION ON ALL MODELS:
BACK OF STOVE

Quadra-Fire 3100 Series Specifications

General

EPA Certified	Yes
Flue Size	6 inches
Efficiency	78%
Firebox Size	2.0 cu ft
Log Length	18 inches
Depth	26.5 inches
Maximum Burn Time	10 hours
