4300 Wood Stove Series (ACC)
B. Glass Replacement
1. Ensure that the fi re is out and the appliance is cool
to the touch.
2. Protect a table or counter top with padding or towels.
Protect your hands and wear gloves to prevent
injury.
3. Remove the door with the broken glass by lifting the
door up and off of the hinges.
4.
Lay door face down on a table or counter making sure
the handle hangs over the edge so the door lays fl at,
on a soft surface.
5. Remove the screws from each glass retainer and
remove the glass. (If screws are diffi cult to remove,
soak with penetrating oil fi rst).
6. Center the glass with edges evenly overlapping the
opening in the door, (i.e. same space top and bottom,
left and right sides).
7. Replace the glass retainers. Be careful not to cross
thread the screws.
8. Tighten each retainer just a few turns until each is
secured. Check again for centering of glass in door
frame. Continue to tighten each retainer alternately,
a few turns at a time, until the glass is secure. DO
NOT OVERTIGHTEN.
9. Replace the door on the appliance.
Quadra-Fire stoves are equipped with ceramic super
heat-resistant glass, which can only be broken by impact
or misuse.
Do not slam stove door or impact the glass. When closing
door, make sure that logs do not protrude against the
glass. Inspect glass regularly.
If you fi nd a crack or break, immediately put the fi re out
and return the door to your dealer for replacement of glass
before further use.
Handle glass with care.
• Inspect the gasket to ensure it is
undamaged.
• Do NOT strike, slam or scratch glass.
• Do NOT operate appliance with glass
& door assembly removed.
WARNING
Glass
Assembly
• Do NOT operate with glass cracked, broken or scratched.
• Use only glass specifi ed in manual.
• DO NOT REPLACE with any other material.
Glass breakage will occur.
WARNING
Fire Risk.
Injury Risk.
