27 04/217058-805F
G. Glass Replacement
1. Open the door from the appliance by lifting door off of
hinge pins and lay on a at surface face down.
2. Using a Phillips Head screw driver, remove the 4
brackets and set aside (Figure 27.1).
3. Remove old glass and replace with the new glass.
4. Re-install the brackets using the same screws.
Figure 27.1
• Glass is 5mm thick high temperature
heat-resistant ceramic glass.
• DO NOT REPLACE with any
other material.
• Alternate material may shatter and
cause injury.
WARNING
1
2
3
4
Glass Assembly
Remove the 4
brackets outlined
in the diagram
