36
Fig. 01
4.14 FUEL TANK
QSI0001
Fig. 02
QSI0023
4.15 PARKING BRAKE LEVER
The parking brake lever «1» is located on the upper part of the inner eg
shield.
When the parking brake lever «1» is in position «3» the wheels spin
freely and the vehicle is in riding mode.
When the parking brake lever «1» is in position «2» the rear wheel and
the HTS system are locked in parking mode.
(Fig. 01)
(Fig. 02)
VEHICLE DESCRIPTION
To gain access to the fuel tank, proceed as follows:
Rotate the ignition switch it counter-clockwise to position «1».
The tank cap flap «2» lifts automatically.
After refuelling always check that the fuel filler cap is cor-
rectly closed and locked
Use only unleaded petrol with min. 95 RON octane rating.
Fuel Tank Capacity: approx. 13 litres
Fuel Reserve Capacity: approx. 2.1 litres
