67
Fig. 02
QSI0056
Fig. 01
QSI0055
• Remove the seven screws «2 - Fig. 01», which the airbox cover in
place.
• Remove the airbox cover «1 - Fig. 01».
• Remove the three air filter retaining screws«3 - Fig. 02».
• Remove the air filter «4 - Fig. 02».
This operation should be carried out more frequently if
you often ride your vehicle over dusty or wet roads.
MAINTENANCE VEHICLE
