68
Fig. 01
QSI0057
Fig. 02
QSI0058
CLEANING
DO NOT USE PETROL OR OTHER FLAMMABLE LI-
QUIDS TO CLEAN YOUR AIR FILTER.
• Gently brush any dirt off the surface with a clean rug.
• Blow compressed air from the inside out, in the direction shown in
the figure.
Refit the airbox following the above procedure in reverse order.
Is highly recommended that you have these
operations performed by an authorised servi-
ce centre or qualified personnel.
6.11 TYRES
The tyre inflation pressure must be checked periodically before riding.
Front tyre Tubeless 110/80-14 53 P
Rear tyre Tubeless 140/70-15 69 P
Front tyre pressure 1,5 bar (22 Psi)
Rear tyre pressure
2,2 bar (32,3 Psi) single driver
2,5 bar (36,2 Psi) with passenger
(Fig. 02)
MAINTENANCE VEHICLE
Too high
Too low
Tyre pressure
