72
Fig. 01
QSI0065
Fig. 02
QSI0066
6.14 FRONT AND REAR BRAKE DISCS
To guarantee your safety, the braking system must al-
ways be kept in perfect working conditions.
The longevity of brake pads is significantly reduced by
dust, mud, etc.
It is highly recommended that you have the-
se operations performed by an authorised
service centre or qualified personnel.
BRAKE PADS
Brake pads must be inspected in accordance with the scheduled
maintenance chart
In order to check the thickness of the brake pad lining, proceed as
follows:
• Rest the vehicle on its centre stand and on level ground.
• Check the thickness of the brake pad lining from the front of the
vehicle and leaning underneath the brake calliper.
MAINTENANCE VEHICLE
