Qualcast cgt183a - Machine Components

ORIGINAL INSTRUCTIONS
18 Volt
Cordless Grass Trimmer
HELPLINE NO 0844 8010979
1. SWITCH LOCK OFF BUTTON
2. BATTERY RELEASE BUTTON
3. BATTERY PACK
4. ON/OFF SWITCH
5. HEAD ROTATION LOCKING MECHANISM
6. HEIGHT ADJUSTMENT LOCKING MECHANISM
7. FLATTENING HEAD ADJUSTMENT BUTTON
8. SAFETY GUARD
9. CUTTING HEAD ASSEMBLY
10. EDGE GUIDE
11. MOTOR HOUSING
12. AUXILIARY HANDLE
13. CUTTING HEAD COVER (See Fig S )
14. CUTTING HEAD COVER RELEASE LATCH (See Fig S )
15. SPOOL (See Fig S )
16. EYELET (See Fig S )
17. CUTTING HEAD (See Fig S )
18. LINE FEED BUTTON (See Fig Q )
1
11
12
10
2
3
5
6
7
8
9
4
