Qualcast MEB1334M - In the Box Contents; Parts List

9
Customer Helpline 08456 400 800
1
Lock-off safety
button
2
Start / Stop switch
levers
3
Cable strain-relief
device
4
Switch box housing
5
Top, curved handle
section
6
Quick release levers
(4 x lever, bolt &
washer)
7
Grass box top
8
Grass collector
9
Cutting height
adjuster
10
Bottom handle
supports
11
Grass box handle
12
Deflector guard
13
Carrying handle
14
Housing
15a
Back wheels
15b
Front wheels
In the Box
Parts
Tools required: cross head screwdriver (to lock the grass collector frame into position. See pages 12-
13. Fig 3c )
1
2
3
4
5
6
7
8
9
15a
15b
10
11
12
13
14
