8
Step 2: Carefully lift the insert into the
mantle opening. The front of the INSERT
should be flush with the front of the mantle.
Step 3: Once the INSERT is in place, attach
3 MOUNTING CLIPS (R) on the top of the
INSERT and lock the insert in place with 3
SHORT KD SCREWS (X). See fig. L
fig. L
Step 4: Attach 2 MOUNTING BRACKET (W) to
the bottom with 2 KD SCREWS. See fig. L
Step 5: Move assembled unit to desired
location. Unit should not be positioned in
area exposed to direct sunlight.
WALL ANCHOR
SAFETY CABLE
The use of WALL ANCHOR SAFETY CABLE
is highly recommended in order to reduce
the risk of the fireplace being tipped over
accidentally. WARNING: This CABLE may
reduce possible risk of injury if the fireplace
is improperly handled, but is not a substi-
tute for proper adult supervision. Children
should not be left unattended near any
heater.
1. Drill a 5/16 in (8 mm) hole in the wall.
Insert the PLASTIC WALL ANCHOR into the
hole and gently tap until the flange on the
anchor is against the wall surface.
2. Position the back edge of the mantle close
to the wall.
3. Attach the SAFETY CABLE to the mantle
using the SCREW FOR MANTLE. See figure
M or N.
4. Use the SCREW FOR WALL to attach the
other end of SAFETY CABLE to the wall.
5. Make sure all screws are tight.
ASSEMBLY INSTRUCTIONS
fig. M
fig. N
