Quanmax KEEX-1760 Series User Manual

Chapter 2
25
KEEX
-
17
6
0 Series Use r’s Manual
Table 10 BAT1 CR2032 Battery Power Input Wafer
Pin Signal Name
1 Battery+
2 Battery
-
Pitch:1.25mm [Pinrex 712-73-02TWR0]
Table 11 COM1~2 RS-232/422/485 Port 1 Wafer
Pin RS-232 RS-422
Half Duple x
RS-485
Full Duplex
RS-485
1 DCD TX
-
DATA
-
TX
-
2 DS
R
N/
A
N/
A
N/
A
3 RXD TX
+
DATA
+
TX
+
4 RT
S
N/
A
N/
A
N/
A
5 TX
D
R
X+ N/
A
R
X+
6 CT
S
N/
A
N/
A
N/
A
7 DT
R
RX
-
N/
A
RX
-
8 RI N/
A
N/
A
N/
A
9 GND GND GND GND
1
0
+5V +5V +5V +5V
Pitch:1.25mm [Pinrex 712-73-10TWB0]
Table 12 COM3~6 RS-232 Port 2 Wafer
Pin Signal Name
1 DCD
2 DS
R
3 RXD
4 RT
S
5 TX
D
6 CT
S
7 DT
R
8 RI
9 GND
1
0
+5V
Pitch:1.25mm [Pinrex 712-73-10TWB0]
Table 13 CN1 DC12V Power Input Wafer
Pin Signal
1 +12Vin
2 GND
3 GND
4 +12Vin
Pitch: 3.0mm WAFER [Pinrex 733-97-04TBR1]
