Quanmax KEEX-1760 Series User Manual

Chapter 2
26
KEEX
-
17
6
0 Series Use r’s Manual
Table 14 CN2 PS/2 Keyboard / Mouse Wafer
Pin Signal Name
1 MSCLK
2 VCC
3 MSDAT
*
4 KBDAT
5 GND
6 KBCLK
Pi tch:2.0m m [YIMT EX 50 3PW1*06ST
-
1R
]
Table 15 CN3 HDD Power Output Wafer
Pin Signal
1 +12V
2 GND
3
GND
4
+5V
Pitch: 2.
0
mm WAFER [
P
inrex 721
-
93
-
04T
W
E9
]
Table 16 CN9 Audio Input / Output Pin Header
11
1 2
12
Pin Signal Name Pin Signal Name
1 MIC
-
In_L 2 M IC
-
In_
R
3 MIC
-
In_JD
#
4 GND
5 Line
-
In_L 6 Line
-
In_
R
7 Line
-
In_JD
#
8 GND
9 Line
-
Out_L 1
0
Line
-
Out_
R
11 Line
-
Out_JD
#
1
2
GND
Pitch:2.54mm [Pinrex 212-92-06GBE1]
Table 17 CN10 SIM Interface Wafer for MPCIe2
Pin Signal Name
1
UIM_PW
R
2
UIM_DATA
3
UIM_RESET
4
UIM _ VPP
5
UIM_CLK
6
GND
Pitch:1.25mm [Pinrex 712-73-06TWB0]
