Installing a Second Tape Drive or Replacing a Tape Drive
Follow these instructions to install a second tape drive or to replace a tape drive after it
has been removed.
Caution: Before installing a second tape drive, you must turn off the 1U Rackmount
enclosure and disconnect it from its AC power source.
Preinstallation
Requirements
Before installing a second tape drive in the 1U Rackmount enclosure, make sure you
have the following required tools and parts:
Installation Procedure The installation procedure is divided into the following major sections:
• Removing the Top Panel
• Adding a Second Tape Drive
• Replacing a Tape Drive:
• Connecting the Tape Drive Cables
• Re-installing the Top Panel
Removing the Top Panel
To remove the top panel:
1 Press the drive power pushbutton switch on the front panel of the 1U Rackmount
enclosure to turn off the drive power.
2 Disconnect the AC power cable from the AC power connector on the back panel of
the 1U Rackmount enclosure.
3 Remove the 1U Rackmount enclosure from the equipment rack and place it on a
clean, stable, flat surface.
4 Remove the top access panel (see Figure 5
):
a Loosen the latch screw
b Lift the latch and slide the top panel toward the back of the 1U rackmount
enclosure.
Tools
3/16 in. (5 mm) flat-blade screwdriver
T-15 Torx driver
Parts
• A supported model tape drive
• Parallel SCSI cable and terminator or SAS cable depending on the
tape drive type
