Installing a Second Tape Drive or Replacing a Tape Drive 5
LTO-3, LTO-4, LTO-5, LTO-6, LTO-7 and LTO-8
c Remove the top access panel from the 1U rackmount enclosure.
Figure 5 Top Access Panel
Adding a Second Tape Drive
Note: If you are replacing a tape drive, refer to Replacing a Tape Drive: on page 7.
To add a second tape drive:
1 Remove the drive blank (see Figure 6
):
a Pull the spring-loaded button on the right mounting rail up.
b Slide the drive blank forward and lift up out of the 1U rackmount enclosure.
1
2
Latch screw
Latch
Top panel
