Quantum ONE O2 - APPENDIX B - QUICK REFERENCE GUIDE

www.quantumcryogenics.com
ONE O2 OXYGEN MONITOR ALARM UNITS Page 17 of 21.
7 APPENDIX B – QUICK REFERENCE GUIDE
REMOTE
CONNECTION SOCKET
CALIBRATION
BUTTON
ADJUSTMENT SCREW
(RECESSED UNDER
FACE)
LOW BATTERY LED
LOW OXYGEN ALARM
LED
CAL HIGH GREEN LED
CAL LOW GREEN LED
AUDIBLE ALARM
SENSOR FILTER
SERIAL NUMBER AND
SERVICE LABELS
REPLACE BY DATE
LABEL
CRITICALLY LOW
OXYGEN ALARM LED
STATUS LED
