19
1. Push the On/Off and Mode Select Lever up once to power on the chair and controller.
2. Push the Menu button to access the Main Menu screen. See figure 6A.
3. Use the joystick to highlight the Handcontrol settings option, then push the joystick to select that
function.
4. Use the joystick to highlight the Bluetooth option, then push the joystick to the right to select that
function.
5. Use the joystick to highlight the Bluetooth function you wish to enable, then push the joystick to the
right to select that function.
NOTE: The first time you select each Bluetooth function, the “Powercycle Needed” message will
appear. To proceed, you must use the On/Off and Mode Select Lever to power off, then power back
on the controller to enable your selected Bluetooth function.
6. Push the joystick forward to enable the Bluetooth screen. See figure 6A.
7. Push the joystick left to select the Esc option and return to the Bluetooth menu.
8. Press the menu button to return to drive mode.
NOTE: This product has been tested for and has passed Electromagnetic and Radio Frequency
Interference (EMI/RFI). Please refer to the Consumer Safety Guide for more information regarding
EMI/RFI. Although we do no recommend using a cell phone while driving a power chair, the system
is capable of receiving and/or making calls through a cell phone device, accessing music files,
contact lists, and navigating a device menu.
Bluetooth Output Power 10 mW
Operation Range 40 m LOS (Line of Sight)
Operating Temperature -40° F to 185° F / -40°C to 85° C
Storage Temperature -67° F to 302°F / -55°C to 150°C
RF Wireless Technology Type Co-existence with IEEE 802.11 (AWMA, AFH)
Encryption security 128-bit
Bluetooth Electronic Specifications
Susceptibility Tested to 20 V/m to IEC 61000-4-3
Emissions To CISPR11, Group 1, Class B
ESD To IEC 61000-4-2
EMC Testing on Sample Wheelchair
