24
Quick Release
Battery Connectors
Front Cover
Release Handles
Battery Wiring Diagram Label
Rear Battery
Front Battery
Battery Set Configuration:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wire to Red Positive (+) Terminal Posts.
Connect Black wire to Black Negative (-) Terminal Posts.
Figure 23. Battery Installation
