4
Q6 EDGE 3 STRETTO
Electronics Box
Rear Shroud
Seat Mount
Interface
Manual
Freewheel
Lever
Drive Wheel
Spring Shock/
Gas Damper
Location
Caster Wheel
Front Riggings
(Foot Platform Shown)
Seatback
Armrest
Joystick
Controller
Seat Base
Front Shroud
SEAT ASSEMBLY
POWER BASE ASSEMBLY
