—25—
D-7 MOTOR ASSEMBLY 1 CW468110012P R
D-8 SHROUD 1 CWL00033
D-9 FAN,PROPELLER 1 CWL00034 R
D-10 CONDENSER ASSEMBLY 1 CW5403R6200C
D-11 ORFICE 1 CWL00036
D-12 DRAIN PIPE 1 CWL00037
D-13 BRACE 1 CWL00071
E-1 CABINET 1 CWL00038
E-2 INSTALLATION KIT 1 CWL00039 R
E-3 GUIDE 1 CWL00040
E-4 OPERATING INSTRUCTION 1 CW382820046C
F FRONT GRILLE ASSEMBLY 1 CW353110182B R
F-1 KNOB ASSEMBLY 2 CW494120002A R
F-2 GRILLE,INLET 1 CW353010133A
F-3 AIR FILTER 1 CW5231R2148H
F-4 GRILE,FRONT 1 CW353010132A
F-5 VANE 6 CWL00047
F-6 VANE 2 CWL00048
F-7 LINK 2 CWL00049
REF. NO DESCRIPTION & NAME Q'TY PART NO.
REMARKS
R: RECOMMANDABLE PARTS
To Next Page
