Quasar HQ-2051TH Service Manual

—24—
7. SERVICE PARTS LIST
A CONTROL BOX ASSEMBLY 1 CWL00001
A-1 POWER CORD ASSEMBLY 1 CWL00002 R
A-2 THERMOSTAT ASSEMBLY 1 CWL00003 R
A-3 SWITCH,ROTARY 1 CWL00004 R
A-4 CAPACITOR 1 CWL00005 R
A-5 CONTROL BOX 1 CWL00006
A-6 COVER 1 CWL00007
A-7 CONDUCTOR ASSEMBLY 1 CWL00008
A-8 CLAMP FOR CAPACITOR 1 CWL00009
A-9 CONDUCTOR ASSEMBLY 1 CWL00010
A-10 CLIP 1 CWL00011
A-11 LEAD WIRE ASSEMBLY 1 CWL00012
B-1 OVERLOAD PROTECTOR 1 CWL00013 R
B-2 COMPRESSOR 1 CW2520ABC2JA R
B-3 RUBBER,MOUNTING 3 CWL00015
B-4 NUT,TERMINAL COVER 1 CWL00016
B-5 GASKET-NUT 1 CWL00017
B-6 COVER 1 CWL00018
B-7 GASKET 1 CWL00019
B-8 HEXAGON NUT 3 CWL00020
B-9 BRACKET,WASHER 3 CWL00021
C-1 TUBE ASSEMBLY,EVAPORATOR IN
1 CW521110063A
C-2 TUBE ASSEMBLY,CAPILLARY 1 CW521030018J
C-3 TUBE ASSEMBLY,SUCTION 1 CW521110062A
C-4 TUBE ASSEMBLY,DISCHARGE 1 CWL00025
C-5 DRIER ASSEMBLY 1 CW585130001L
D-1 EVAPORATOR ASSEMBLY 1 CWL00026
D-2 CLAMP SPRING 2 CWL00027
D-3 FAN,TURBO 1 CWL00028 R
D-4 AIR GUIDE 1 CWL00029
D-5 AIR GUIDE 1 CWL00030
D-6 BASE ASSEMBLY 1 CWL00031
REF. NO DESCRIPTION & NAME Q'TY PART NO. REMARKS
R: RECOMMANDABLE PARTS
