M66 Hardware Design
M66_Hardware_Design Confidential / Released 64 / 80
DATA Mode, GPRS ( 3 Rx, 2Tx ) CLASS 12
GSM850
@power level #5 <550mA, Typical 363mA
@power level #12, Typical 131mA
@power level #19, Typical 91mA
EGSM900
@power level #5 <550mA, Typical 393mA
@power level #12, Typical 132mA
@power level #19, Typical 92mA
DCS1800
@power level #0 <450mA, Typical 268mA
@power level #7, Typical 112mA
@power level #15, Typical 88mA
PCS1900
@power level #0 <450mA, Typical 257mA
@power level #7, Typical 119mA
@power level #15, Typical 89mA
DATA Mode, GPRS ( 2 Rx, 3Tx ) CLASS 12
GSM850
@power level #5 <640mA, Typical 506mA
@power level #12, Typical 159mA
@power level #19, Typical 99mA
EGSM900
@power level #5 <600mA, Typical 546mA
@power level #12, Typical 160mA
@power level #19, Typical 101mA
DCS1800
@power level #0 <490mA, Typical 366mA
@power level #7, Typical 131mA
@power level #15, Typical 93mA
PCS1900
@power level #0 <480mA, Typical 348mA
@power level #7, Typical 138mA
@power level #15, Typical 94mA
DATA Mode, GPRS ( 4 Rx,1Tx ) CLASS 12
GSM850
@power level #5 <350mA, Typical 216mA
@power level #12, Typical 103mA
@power level #19, Typical 83mA
EGSM900
@power level #5 <350mA, Typical 233mA
@power level #12, Typical 104mA
@power level #19, Typical 84mA
DCS1800
@power level #0 <300mA, Typical 171mA
@power level #7, Typical 96mA
@power level #15, Typical 82mA
PCS1900
@power level #0 <300mA, Typical 169mA
@power level #7, Typical 98mA
@power level #15, Typical 83mA
DATA Mode, GPRS ( 1 Rx, 4Tx ) CLASS 12
