EM05 Hardware Design
EM05_Hardware_Design Confidential / Released 21 / 59
The following figure shows the connection between the module and the host.
USB_DP
USB_DM
USB_DP
USB_DM
Module
Host
GND
GND
WOWWAN#
EINT
Figure 4: Sleep Mode Application with WOWWAN#
 Sending data to EM05 through USB will wake up the module.
 When EM05 has a URC to report, WOWWAN# signal will wake up the host.
3.4.2. Airplane Mode
When the module enters into airplane mode, the RF function does not work, and all AT commands
correlative with RF function will be inaccessible. This mode can be set via the following ways.
Hardware:
The W_DISABLE1# pin is pulled up by default; driving it to low level will let the module enter into airplane
mode.
Software:
AT+CFUN command provides the choice of the functionality level.
 AT+CFUN=0: Minimum functionality mode; both (U)SIM and RF functions are disabled.
 AT+CFUN=1: Full functionality mode (by default).
 AT+CFUN=4: Airplane mode. RF function is disabled.
For details of related AT commands, please refer to document [2].
1. The W_DISABLE1# control function is disabled in firmware by default. It can be enabled by
AT+QCFG="airplanecontrol" command. This command is under development.
2. The execution of AT+CFUN command will not affect GNSS function.
