Quectel EC200A Series User Manual

LTE Standard Module Series
DCS1800 PCL = 15 @ -0.43 dBm
46.8
mA
WCDMA voice call
WCDMA B1 @ 22.77 dBm
557.69
mA
WCDMA B5 @ 22.42 dBm
483.34
mA
WCDMA B8 @ 22.43 dBm
529.50
mA
EC200A-AU
Description
Conditions
Typ.
Unit
OFF state
Power down
10
uA
Sleep state
AT+CFUN=0 (USB disconnected)
0.95
mA
EGSM900 @ DRX = 2 (USB disconnected)
1.67
mA
EGSM900 @ DRX = 5 (USB disconnected)
1.29
mA
EGSM900 @ DRX = 5 (USB suspend)
TBD
mA
EGSM900 @ DRX = 9 (USB disconnected)
1.28
mA
DCS1800 @ DRX = 2 (USB disconnected)
1.66
mA
DCS1800 @ DRX = 5 (USB disconnected)
1.30
mA
DCS1800 @ DRX = 5 (USB suspend)
TBD
mA
DCS1800 @ DRX = 9 (USB disconnected)
1.19
mA
WCDMA @ PF = 64 (USB disconnected)
2.30
mA
WCDMA @ PF = 64 (USB suspend)
TBD
mA
WCDMA @ PF = 128 (USB disconnected)
2.29
mA
WCDMA @ PF = 256 (USB disconnected)
1.67
mA
WCDMA @ PF = 512 (USB disconnected)
1.36
mA
LTE-FDD @ PF = 32 (USB disconnected)
TBD
mA
LTE-FDD @ PF = 64 (USB disconnected)
TBD
mA
LTE-FDD @ PF = 64 (USB suspend)
TBD
mA
LTE-FDD @ PF = 128 (USB disconnected)
TBD
mA
