Quectel EC200A Series

LTE Standard Module Series
WCDMA B8 @ 22.61 dBm
593
mA
EC200A-EU
Description
Conditions
Typ.
Unit
OFF state
Power down
10
uA
Sleep state
AT+CFUN=0 (USB disconnected)
0.78
mA
EGSM900 @ DRX = 2 (USB disconnected)
1.50
mA
EGSM900 @ DRX = 5 (USB disconnected)
1.12
mA
EGSM900 @ DRX = 5 (USB suspend)
1.28
mA
EGSM900 @ DRX = 9 (USB disconnected)
1.01
mA
DCS1800 @ DRX = 2 (USB disconnected)
1.50
mA
DCS1800 @ DRX = 5 (USB disconnected)
1.11
mA
DCS1800 @ DRX = 5 (USB suspend)
1.28
mA
DCS1800 @ DRX = 9 (USB disconnected)
1.00
mA
WCDMA @ PF = 64 (USB disconnected)
2.11
mA
WCDMA @ PF = 64 (USB suspend)
2.25
mA
WCDMA @ PF = 128 (USB disconnected)
1.47
mA
WCDMA @ PF = 256 (USB disconnected)
1.15
mA
WCDMA @ PF = 512 (USB disconnected)
0.99
mA
LTE-FDD @ PF = 32 (USB disconnected)
1.85
mA
LTE-FDD @ PF = 64 (USB disconnected)
1.28
mA
LTE-FDD @ PF = 64 (USB suspend)
1.43
mA
LTE-FDD @ PF = 128 (USB disconnected)
1.02
mA
LTE-FDD @ PF = 256 (USB disconnected)
0.89
mA
LTE-TDD @ PF = 32 (USB disconnected)
1.88
mA
LTE-TDD @ PF = 64 (USB disconnected)
1.29
mA
