Quectel EC200T-EU User Manual

LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 59 / 90
LTE-FDD B3 1710–1785 1805–1880 MHz
LTE-FDD B5 824–849 869–894 MHz
LTE-FDD B8 880–915 925–960 MHz
LTE-TDD B34 2010–2025 2010–2025 MHz
LTE-TDD B38 2570–2620 2570–2620 MHz
LTE-TDD B39 1880–1920 1880–1920 MHz
LTE-TDD B40 2300–2400 2300–2400 MHz
LTE-TDD B41 2555–2655 2555–2655 MHz
Table 28: EC200T-EU Operating Frequencies
3GPP Band Transmit Receive Unit
EGSM900 880–915 925–960 MHz
DCS1800 1710–1785 1805–1880 MHz
WCDMA B1 1920–1980 2110–2170 MHz
WCDMA B8 880–915 925–960 MHz
LTE-FDD B1 1920–1980 2110–2170 MHz
LTE-FDD B3 1710–1785 1805–1880 MHz
LTE-FDD B7 2500–2570 2620–2690 MHz
LTE-FDD B8 880–915 925–960 MHz
LTE-FDD B20 832–862 791–821 MHz
LTE-FDD B28 703–748 758–803 MHz
LTE-TDD B38 2570–2620 2570–2620 MHz
LTE-TDD B40 2300–2400 2300–2400 MHz
LTE-TDD B41 2555–2655 2555–2655 MHz
