Quectel EC200U-CN

LTE Standard Module Series
EC200U_Series_Hardware_Design 75 / 94
Table 45: EC200U-AU Current Consumption
DCS1800 PCL = 0 @ 30.24 dBm
175
mA
DCS1800 PCL = 7 @ 16.2 dBm
75.4
mA
DCS1800 PCL = 15 @ 0.87 dBm
57.7
mA
PCS1900 PCL = 0 @ 29.8 dBm
168
mA
PCS1900 PCL = 7 @ 16.6 dBm
78
mA
PCS1900 PCL = 15 @ 0.8 dBm
59
mA
Description
Conditions
Typ.
Unit
OFF state
Power down
TBD
μA
Sleep state
AT+CFUN = 0 (USB disconnected)
TBD
mA
GSM850 @ DRX = 2 (USB disconnected)
TBD
mA
GSM850 @ DRX = 5 (USB disconnected)
TBD
mA
GSM850 @ DRX = 5 (USB suspend)
TBD
mA
GSM850 @ DRX = 9 (USB disconnected)
TBD
mA
DCS1800 @ DRX = 2 (USB disconnected)
TBD
mA
DCS1800 @ DRX = 5 (USB disconnected)
TBD
mA
DCS1800 @ DRX = 5 (USB suspend)
TBD
mA
DCS1800 @ DRX = 9 (USB disconnected)
TBD
mA
LTE-FDD @ PF = 32 (USB disconnected)
TBD
mA
LTE-FDD @ PF = 64 (USB disconnected)
TBD
mA
LTE-FDD @ PF = 64 (USB suspend)
TBD
mA
LTE-FDD @ PF = 128 (USB disconnected)
TBD
mA
LTE-FDD @ PF = 256 (USB disconnected)
TBD
mA
LTE-TDD @ PF = 32 (USB disconnected)
TBD
mA
