Quectel EC200U-EU User Manual

LTE Standard Module Series
EC200U_Series_Hardware_Design 81 / 94
Table 51: EC200U-AU Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP
Primary
GSM850
TBD
-102.0 dBm
EGSM900
TBD
-102.0 dBm
DCS1800
TBD
-102.0 dBm
PCS1900
TBD
-102.0 dBm
LTE-FDD B1 (10 MHz)
TBD
-96.3 dBm
LTE-FDD B2 (10 MHz)
TBD
-94.3 dBm
LTE-FDD B3 (10 MHz)
TBD
-93.3 dBm
LTE-FDD B4 (10 MHz)
TBD
-96.3 dBm
LTE-FDD B5 (10 MHz)
TBD
-94.3 dBm
LTE-FDD B7 (10 MHz)
TBD
-94.3 dBm
LTE-FDD B8 (10 MHz)
TBD
-93.3 dBm
LTE-FDD B28 (10 MHz)
TBD
-94.8 dBm
LTE-FDD B66 (10 MHz)
TBD
-96.3 dBm
LTE-TDD B38 (10 MHz)
TBD
-96.3 dBm
LTE-TDD B40 (10 MHz)
TBD
-96.3 dBm
LTE-TDD B41 (10 MHz)
TBD
-94.3 dBm
5.7. ESD
If the static electricity generated by various ways discharges to the module, the module maybe damaged
to a certain extent. Thus, please take proper ESD countermeasures and handling methods. For example,
wearing anti-static gloves during the development, production, assembly and testing of the module;
adding ESD protective components to the ESD sensitive interfaces and points in the product design.
The following table shows the module electrostatics discharge characteristics.

Quectel EC200U-EU Specifications

General

Module Type	LTE Cat 1 Module
Form Factor	LCC
Operating Temperature	-40°C to +85°C
Storage Temperature	-45°C to +90°C
LTE Category	Cat 1
Max Downlink Speed	10 Mbps
Max Uplink Speed	5 Mbps
LTE Bands	B1/B3/B5/B7/B8/B20
LTE-TDD Bands	B38/B40/B41
UMTS Bands	B1/B5/B8
GSM Bands	900/1800 MHz
Antenna Pad	Yes
Power Supply	3.3V to 4.3V
Data Rate UMTS	384 kbps
Voice	VoLTE
GNSS	GPS, GLONASS, BeiDou
Interfaces	USB 2.0, UART, I2C, GPIO
SIM Interface	1.8V/3.0V
Protocols	HTTP/HTTPS, FTP
Certifications	CE, FCC, RCM, GCF
