LTE
Module
Series
EG21-G
Hardware
Design
EG21
-
G_Hardware_Design
37
/
100
Table 8
:
RESET_N Pin Description
Pin Name
Pin No.
I/O
Description
Comment
RESET_N
20
DI
Reset the module
1.8V power domain
The
recommended
circuit
is
similar
to
the
PWRKEY
control circuit. A
n
open
drain/collector driver
or
button
can be used to control the RESET_N.
Reset pulse
RESET_N
4.7K
47K
150ms~460ms
Figure
14
: Reference Circuit of RESET_N by Using Driving Circuit
RESET_N
S2
Close to S2
TVS
Figure
15
: Reference Circuit of RESET_N by Using Button
The reset scenario is illustrated
in
the following figure.
