Quest Engineering PR-130A - Specifications

Specifications:
Performance
Model Number PR-130A PR-240A
Frequency Response at 1watt from speaker out tap, 100Hz~10kHz
+1.5 / -3 dB
Tone Control, 100Hz,10KHz ±12dB ±3dB
Signal to Noise Ra�o at rated power output Less than 90dB
Crosstalk at all control maximum -70dB at 1kHz
Rated Output Power at THD 0.5% 130W 240W
Total Harmonic Distor�on(THD)at 1kHz rated power output Less than 0.5%
Phantom Power +48 VDC
Power Band Width at 1kHz from speaker out tap 80Hz~15kHz with less than 0.5% THD
DC Output Offset
Less than ±3mV
Opera�ng Temperature/Humidity at non-condensing 0°~40°C at 95% humidity
Cooling Construction Convection Cooled
Carton Dimensions (Width/Depth/Height)
20.7(W) x 16.5(D) x 7.6(H) inches
525(W) x 420(D) x 193(H) mm
Net Weight 22.05 lbs (10 kg) 24.25 lbs (11 kg)
Protection
Over current / Over temperature /
Under voltage / DC fault
– 17 –
PR-130A / PR-240A
