Screen House and accessories full instructions
Screen House 4
Roof Frame Diagram
Code: 120053 • Diagram Version 1
152cm
Roof poles
11mm diameter
Solid Fibreglass
Pole end caps
(hub end)
Pole end caps
(sleeve end)
Roof hub
2 Pieces
(top and bottom)
Screen House 4
Side Frame Diagram
Code: 120053 • Diagram Version 1
133cm
Roof poles
11mm diameter
Solid Fibreglass
Pole end caps
(hub end)
Pole end caps
(sleeve end)
Roof hub
2 Pieces
(top and bottom)
155cm
