17
r. Boiler lifting indicator light
SIZE lxhxp:
WEIGHT:
VOLTAGE:
POWER:
TANK CAPACITY:
BOILER CAPACITY:
TEMPERATURE:
290X405X445 mm
24 KG
220/230V – 50/60HZ - 115V – 60HZ
1500W
3 L
1,60 LITRES
+5°C / 45°C
Commissioning
1. Open the tank filler lid.
2. Fill the tank (n) with drinking water, softened if possible.
3. Connect the machine to an electric socket. Switch on the machine through
the general switch (o) in postion 1, the green light (p) switches on.
4. The machine fills the boiler, indicated by the red light (r) that switches on.
5. Activate the coffee delivery group through the lever (b), deliver water from
the group to make sure that the circuit is correctly filled.
6. Wait for the machine to reach the operating temperature indicated by the
red light (q) that switches off and by the pointer of the boiler gauge
(h) that is to indicate a value between 1 Bar and 1.5 Bar.
Coffee brew
1. Remove the filter holder (c) from its seat, turning it clockwise.
2. Fill the filter with one or two doses of coffee (according to the filter
inserted).
3. Press the coffee with the presser.
4. Place the filter holder (c) to its seat, turning it anti-clockwise.
5. Place the cups under the corresponding outlets under the filter holder.
6. Lift the coffee delivery lever (b) to the horizontal position to start the coffee
brew, and after a few seconds starts the coffee brew.
When the desired amount of coffee has been delivered, lower the group
lever to the vertical position.
