Quick 3202 User Manual

(1) Use about the clean sponge.
 Dampen the small cleaning sponge with water and then squeeze it
dry.
 Place the small sponge in groove of the iron holder base.
 Add a little water to iron holder. The small sponge will absorb
water to keep the large sponge around it wet at all times.
 Dampen the large cleaning sponge and place it on the iron holder
base.
CAUTION:

The clean sponge is compressed. It will swell when moistened
with water. Before using the unit, moisten the sponge with the
water and squeeze it dry. Failure to do so may result in damage
to the soldering tip.

If the sponge becomes dry during work, add appropriate water.
(2) Use about the metal sponge.
When cleaning the tip with the metal sponge, insert the tip into the metal
sponge and then revolve it lightly, after cleaning, coat it with fresh
solder.
4.2 Connection
CAUTION:
Be sure to turn off the power switch before connecting or
disconnecting the unit. Failure to do so may damage it.
1. Connect the connector of the iron handle cord to the handle socket of the unit.
Take notice of the inserting position about the connector.
2. Place the soldering iron handle into the iron holder.
3. Insert power plug into grounded power socket.
4. Turn on the unit.
Ⅷ. Use and Maintenance of the Tip
8.1 Use of the Tip
1. Tip temperature
High temperature will shorten lifetime of the soldering tip. Choose a low and
suitable soldering temperature if possible. With the excellent thermal recovery,
it can ensure a sufficient and effective soldering event at low temperature to
protect sensitive components from damage.
2. Cleaning
The remnant flux during soldering process will form oxides and carbides which
will cause damage to the tip, soldering difference and thermal recovery
decreasing. Clean the tips regularly with the cleaning sponge.
Remove the oxides and carbides once a week if using the soldering station
continuously to protect the tip.
3. When not in use
When the work is finished, don’t leave the soldering station at high
temperature for long time. Or the flux in the tip will turn to oxides and carbides
which will reduce the heat conductivity of the tip largely.
4. After use
Wipe the tip and coat it with fresh solder. This will protect the tip from
oxidation.
8.2 Maintenance of the Tip
1. Inspect and Clean the Tip
CAUTION: Never file the tip to remove oxide.
(1) Set the temperature to 250℃.
Page 5
