QUICK AL3Series INSTALLATION AND USER’S MANUAL - REV000A
10
WINDLASS
CONTACTOR BOX
T6315-12 (12V)
T6315-24 (24V)
FOOT-OPERATED SWITCHES MOD. 900U E 900D
BLACK
BROWN
BLUE
FUSE
4A (12V)
2A (24V)
RRC R02 RECEIVER
POCKET-SIZE RRC P02
PUSHBUTTON
PANEL RRC H02
PANEL CHAIN-COUNTER
CHC 1203 - QNC CHC
CONTROLS FOR CONTROL
BOARD WCS 820 - WCS
B - WCS 830
CHAIN-COUNTER
PUSH-BUTTON PANEL
CHC 1103
RRC REMOTE RADIO CONTROLS
WCS 830
WINDLASS CONTROL SWITCH
TRANSMITTERS
MULTI-PURPOSE
PUSH-BUTTON
PANEL HRC 1002
5.0 - Example of connection AL3 Series 700W P - 1000W P - 1500W
with recommended Quick
®
accessories for the operation of the windlass
MOTOR
BROWN BLACK BLUE
L1
L2
L3
L3
L4
A2
A1
C
L = L1 + L2 + L3 + L4
5 - Wiring diagram
