AL3 Series
EN
AL3 P 10 12 D
QUICK AL3Series INSTALLATION AND USER’S MANUAL - REV000A
5
1.0 - Model code
VOLTAGE (V)
GEARBOX:
TECHNOPOLYMER (P)
ALUMINIUM (-)
SERIES NAME
POWER
(W)
DRUM (D)
NO DRUM (-)
1.1 - Technical Data
MODELS AL3 P - / D AL3 - / D
MODEL POWER 700W 1000W 1500W
Motor voltage 12V 24V 12V 24V 12V 24V
Maximum instantaneous pull 850 kg (1874 lb) 1000 Kg (2205 lb) 1100 Kg (2425 lb)
Maximum work load 250 Kg (551 lb) 300 Kg (661 lb) 370 Kg (816 lb) 450 Kg (992 lb) 470 kg (1036 lb) 540 kg (1190 lb)
Work load 80 Kg (176,4 lb) 100 Kg (221 lb) 120 kg (265 lb) 150 Kg (331 lb) 160 Kg (353 lb) 180 kg (397 lb)
Current consumption at work
load
(1)
90 A 55 A 140 A 80 A 155 A 85 A
Maximum recovery speed
(2)
27,4 m/min
(89,9 ft/min)
26,4 m/min
(86,6 ft/min)
39,6 m/min
(129,9 ft/min)
40,9 m/min
(134,2 ft/min)
29,2 m/min
(95,8 ft/min)
29,7 m/min
(97,4 ft/min)
Recovery speed at work load
(2)
14,4 m/min
(47,2 ft/min)
14,8 m/min
(48,5 ft/min)
20,4 m/min
(66,9 ft/min)
21,4 m/min
(70,2 ft/min)
16,3 m/min
(53,5 ft/min)
19 m/min
(62,3 ft/min)
Minimum motor cable cross
section
(3)
25 mm²
(AWG3)
10 mm
2
(AWG7)
35 mm
2
(AWG2)
16 mm²
(AWG5)
50 mm²
(AWG0)
25 mm²
(AWG3)
Circuit breaker
(4)
50 A 40 A 80 A 50 A 100 A 50 A
Deck thickness
(5)
25 ÷ 50 mm (63/64” ÷ 1” 31/32) 30 ÷ 50 mm (1” 3/16” ÷ 1” 31/32)
Weight-model without drum 17,4 Kg (38,4 lb) 18,6 Kg (41 lb) 22,4 Kg (49 lb)
Weight-model with drum 18,5 Kg (40,8 lb) 19,7 Kg (43,43 lb) 23,5 Kg (51,80 lb)
(1) After an initial period of use.
(2) Measurements taken with a gypsy for 8 mm chain
(3) Minimum recommended value for total length L= <20 m.
Determine the cable cross section according to the length of the wiring.
(4) With specic circuit breaker for direct current (DC) and delayed circuit breaker (thermal-magnetic or hydraulic-magnetic).
(5) On request, shafts and studs can be supplied for greater deck thicknesses.
GYPSY (*) 8 mm - 5/16” 10 mm - 3/8”
Chain size
8 mm 8 mm 5/16” 5/16” 10 mm 3/8”
DIN 766 ISO G4 BBB ISO (P.30) G4
Rope size (**) 1/2” (12,7 mm) - 9/16” (14,2 mm) - 5/8” (15,8 mm) 5/8” (15,8 mm)
(*) For gypsy codes, see the exploded drawing on page 14
(**) The values in the table apply to the combination of rope and chain according to the Quick® system, we do not guarantee
the correct operation with other anchor-rode types.
BEFORE USING THE WINDLASS READ THESE INSTRUCTIONS CAREFULLY.
IF IN DOUBT, CONTACT YOUR NEAREST “QUICK
®
” DEALER.
QUICK® RESERVES THE RIGHT TO MODIFY THE TECHNICAL CHARACTERISTICS OF THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT
PRIOR NOTICE. IN CASE OF DISCORDANCE OR ERRORS IN TRANSLATION BETWEEN THE TRANSLATED VERSION AND THE ORIGINAL TEXT IN THE ITALIAN
LANGUAGE, REFERENCE WILL BE MADE TO THE ITALIAN TEXT.
1 - Information about the product
