Quick ARIES User Manual

300 / 500 W ARIES - FLAIR - / D 500 W RIDER - / D
54
58
82
170
290
114
74
135
114
82
290
76
Ø 120
128
137
10
TECHNICAL DATA
1° EXAMPLE : FLAIRW312D
FLAIRW 3 12 D

2° EXAMPLE : RIDER524
RIDER 5 24
–

HOW TO IDENTIFY THE WINDLASS THROUGH THE CODE:
GB
a b c d a b c d
Name of the line:
[ ARIES ] = oval base in aluminium
[ FLAIR B ] = oval base in black fiber-glass
[ FLAIR W ] = oval base in white fiber-glass
[ RIDER ] =round base in aluminium
Motor output:
[ 3 ] = 300 W
[ 5 ] = 500 W
Motor supply voltage:
[ 12 ] = 12 V
[ 24 ] = 24 V
Drum:
[D] = with drum
[
– ] = without drum
ARIES – / D
300 W 500 W
12 V 12 V 24 V
350 kg 660 kg
100 kg 200 kg 220 kg
30 kg 65 kg 70 kg
45 A 80 A 40 A
14,7 25,2 25,2
11,9 18,2 19,3
10 mm
2
16 mm
2
10 mm
2
40 A 60 A 40 A
7,6 kg
8,7 kg
FLAIR – / D
300 W 500 W
12 V 12 V 24 V
350 kg 660 kg
100 kg 200 kg 220 kg
30 kg 65 kg 70 kg
45 A 80 A 40 A
14,7 25,2 25,2
11,9 18,2 19,3
10 mm
2
16 mm
2
10 mm
2
40 A 60 A 40 A
7,3 kg
8,4 kg
RIDER – / D
500 W
12 V 24 V
660 kg
200 kg 220 kg
65 kg 70 kg
80 A 40 A
25,2 25,2
18,2 19,3
16 mm
2
10 mm
2
60 A 40 A
7,4 kg
8,5 kg
MODEL
MOTORE OUTPUT
Motor supply voltage
Maximum pull
Maximum working load
Working load
Current absorption @ working load
(1)
Maximum chain speed
(2)
m/min
Maximum chain speed @ working load
(2)
m/min
Chain size
(3)
Rope size
Motor cable size
(4)
Protection circuit breaker
(5)
Deck thickness
(6)
Weight - model without drum
Weight - model with drum
(1)
After an initial period of use.
(2)
Measurements taken with a gypsy for a 6 mm chain.
(3)
All models are supplied with a gypsy for a 6 mm chain as a standard part. On request, gypsies for the chains shown in the chart can be installed.
(4)
Minimum allowable value. Determine the cable size according to the length of the wiring.
(5)
With circuit breaker designed for direct currents (DC) and delayed-action (thermal-magnetic or hydraulic-magnetic).
(6)
On request, shafts and studs can be supplied for greater deck thicknesses.
“QUICK” RESERVES THE RIGHT TO INTRODUCE CHANGES TO THE EQUIPMENT AND THE CONTENTS OF THIS MANUAL WITHOUT PRIOR NOTICE.
6 mm DIN 766 ( 7 mm - 1/4” DIN 766 )
12 mm - 14 mm - 16 mm - 1/2” - 9/16” - 5/8”
20 ÷ 30 mm
DIMENSIONS OF MODELS (mm)
a b c d
