WARNING: make sure the electrical power to
the motor is switched off when working
manually on the windlass. Carefully remove the
chain or rope from the gypsy or the rope from
the drum.
QUICK windlasses are manufactured with materials
resistant to marine environments. In any case, any salt
deposits on the outside must be removed periodically
to avoid corrosion and damage to the equipment. The
parts where salt may have built up should be washed
thoroughly with fresh water.
Once a year, the drum and the gypsy are to be taken
apart as follows:
DRUM VERSION
Use the handle (45) to loosen the bush (44); pull off
the drum (43) and the top clutch cone (39); loosen the
fixing screws (2 or 13) of the rope/chain stripper (3 or
12) and remove it. Pull off the gypsy (41).
NO-DRUM VERSION
Use the handle (45) to remove the gypsy cover (42);
remove the top clutch cone (39); loosen the fixing
screws (2 or 13) of the rope/chain stripper (3 or 12)
and remove it and pull off the gypsy (41).
Clean all the parts removed to avoid corrosion, and
grease the shaft thread (30 and 31) and the gypsy (41)
where the clutch cones rest (use grease suitable for
marine environment) (39).
Periodically grease the hinge pin (7) of the inspection
door (only windlasses with aluminium bases).
Remove any oxide deposits from the terminals of the
electric motor and the reversing solenoid unit; grease
them.
POS. DESCRIPTION CODE
7 Pin
MSR04X000000
8 Screw for pressure lever MSMVT0400000
9A Black pressure lever PDLVTD040000
9B White pressure lever PDLVTD04W000
10 Spring for pressure lever MMTND0400000
11 Rider base SGMSC04C0000
12 Rope/chain stripper Rider base MSC04CX00000
13 Rider screw MBV0620MXSC0
14 Gasket / Rider jig PGBSC0400000
15A Studs Aries base MBP080607X00
15B Studs Flair base MBP080608X00
16 Gearbox MR0400000000
17 Washer MBR08X000000
18 Spring washer MBR08XDE0000
19 Nut MBD08MXEN000
20 Nut MBV0516MXE00
21 Paper gasket
PGBMR0400000
22 Key MBH040415F00
23A Electric motor 300W 12V EMF031200000
23B Electric motor 500W 12V EMF051200000
23C Electric motor 500W 24V EMF052400000
24 Flange gasket 500W
PGGPMFN04000
25 Watertight 500W PCCCPM040000
26 Poles gasket 500W PGGPMPM04000
27 Bottom protec cover 500W PCCPPMFN0400
28 Screw MBV03916AXCC
29 Key MBH060650F00
30 Short shaft MSAS04203R10
31 Long shaft MSAS04245R10
32 Key MBH060625F00
33 Key MBH060660F00
34 External circlip MBAE1715Y000
35 Bearing MBJ60032RS10
36 Internal circlip MBAN3515Y000
37 Oil seal PGPRL1735700
38 Ring MBAC1720Y000
39 Clutch cone MSF04R100000
40 Magnet KPMC08060000
41 Gypsy ZSB040600000
42 Gypsy cover MSGB04000R01
43 Drum MSE040000R02
44 Bush MSD040000R02
45 Handle MSHD00000000
MAINTENANCE
