EN
BTQ SERIES INSTALLATION AND USE MANUAL - IT EN - REV001A
33
BTQ series7 - Warnings
In case the bow thruster needs to be installed on the
opposite position, the connection of the two wires (blue
and grey) to the control cable on the reversing contactor
unit must be inverted.
• This thruster is not designed for continuous use. It is equipped with protections which limit its operation at a maxi-
mum time span, as reported on the controls’ manual.
It is strongly forbidden to bypass or modify such protections in order to increase the operating time span, lest voiding
the warranty and thus lifting any responsibility from Quick SPA.
• Make sure no swimmers or oating objects are in the vicinity before switching on the thruster.
• There must not be ammable materials in the peak or in the area where the Thruster motor is.
• Do not operate the bow thruster out of the water for more than 10 seconds.
• During mooring, it is recommended not to leave in the water any free line, which may be sucked in by the propel-
lers, thus leading them to break.
7.0 - Warnings
8.0 - Use of bow thruster
Start-up
Start-up happens following activation of a THC panel.
To use the thruster refer to the manual of the THC control.
8 - Usage BTQ series
NOTE: the bow thruster must be installed with the RH
propeller on the right-hand side of the gearleg (see gure).
NOTE: the bow thruster must be installed with the RH
propeller on the right-hand side of the gearleg (see gure).
RHRH
SINGOL PROPELLER DOUBLE PROPELLER
