WARNING - USE
WARNING
WARNING:
this bow thruster is not designed for continuous use.
It is equipped with protections which limit its operation at a maximum time span, as reported on the controls’ manual.
It is strongly forbidden to bypass or modify such protections in order to increase the operating time span, lest voiding the
warranty and thus lifting any responsibility from Quick SPA.
WARNING:
make sure no swimmers or floating objects are in the vicinity before switching on the thruster.
WARNING:
there must not be flammable materials in the peak or in the area where the Bow Thruster motor is.
WARNING:
do not operate the bow thruster out of the water for more than 10 seconds.
WARNING:
during mooring, it is recommended not to leave in the water any free line, which may be sucked in by the
propellers, thus leading them to break.
USE OF BOW THRUSTER
START-UP
Start-up happens following activation of a TCD panel.
To use the thruster refer to the manual of the TCD control.
In case the bow thruster needs to be installed on the opposite position, the connection of the two wires (blue and grey) to the
control cable on the reversing contactor unit must be inverted.
NOTE:
the bow thruster must be installed with the propeller
on the right-hand side of the gearleg (see figure).
NOTE:
the bow thruster must be installed with the
RH
propeller on the right-hand side of the gearleg (see figure).
RHRH
SINGOL PROPELLER DOUBLE PROPELLER
