MAINTENANCE
POS.
DESCRIPTION
1 Motor mounting screw
2 Motor mounting washer
3 Motor
4 Even tension device
5 Half-joint
6 Motor flange
7 Gearbox gasket
8 O-Ring
9 Key
10 Gearleg (single propeller)
11 Gearleg (double propeller)
12 Propeller drive pin
13 Right propeller (RH)
14 Left propeller (LH)
15 Propeller mounting nut
16 Anode tip
17 Anode tip mounting screw
18 Washer
19 Gearleg mounting screw
20 Reversing
contactor
unit
21 Clamp reversing
contactor unit
22 Washer
23
Screw
24 Grower
25 Reversing
contactor unit
mounting screw
26 BTQ thermal protection + cable
27 Command wire
28 Carter spacer B
29 Carter reversing
contactor
unit
30 Fasteners carter reversing
contactor
Quick
®
Thrusters are made in materials that are resistant to the sea
environment: In any case, it is indispensable to periodically remove
salt deposits that form on the outer surfaces to avoid corrosions
and consequent system inefficiency.
WARNING:
make sure that the power supply to the electric
motor is not switched on when maintenance operations are
carried out.
Dismantle once a year, following the points below:
• Clean propellers (13 and 14), tunnel and gearleg (10 or 11).
• Replace the zinc anodes (carry out this operation more often if
needed).
• Replace the propellers if damaged or worn out.
• Check the tightness of all screws.
• Ensure that there is no water seepage inside.
• Check that all electrical connections are well tightened and
oxide-less.
• Check that the batteries are in good conditions.
WARNING:
do not paint the anodes (16), the sealing and the
gearleg’s shafts where the propellers is lodged.
