BTR185 INSTALLATION AND USE MANUAL - REV009A
37
BTR1855 - Connection diagram
5.0 - BTR185 basic system
M1
A A
S S
SX
+
-
DX
-
M2
RTC R1
ELECTRONIC BOARD
BATTERY
12/24V
BATTERY ISOLATOR
BLACK
FUSE 4A
QUICK
ACTING F
FUSE
SEE TABLE
ON PAGE 26
SWITCH
RED
BLACK
RED
TO THE SERVICES
BATTERY
TCD 1042
TCD 1022
SPLITTER
(OPTIONAL)
CONTROL CABLE
EXTENSIONS
(OPTIONALS)
*
*
MOTOR
Connection example
TO THE SERVICES
BATTERY
ACTUATOR
SWITCH
*
1 2
4
6
5
3
7
FUSE 10A
QUICK ACTING F
*
COMMON NEGATIVE FOR THE BATTERY GROUPS.
**
WARNING: IN CASE OF OVERTEMPERATURE, THE THERMAL PROTECTION ON THE MOTOR WILL OPEN AND INTERRUPT THE NEGATIVE CONTACT ON THE SOLENOID UNIT. WAIT AS LONG
AS THE SYSTEM NEEDS TO REACTIVATE.
**
THERMIC
PROTECTION
