Quick DYLAN DH User Manual

18
GB
DYLAN DH 1500/1700/2000W - REV001A
24V
KM1
W2
U1
R
S
T
L
1 XP
PE XP
R
V1 W1
U1
V1
W1
XP XP XP
U2 V2
U1 V1 W1
24V
KM2
FU1 13-25A aM
FU1 13-25A aM
L
2 XP S
FU1 13-25A aM
L
3 XP T
R
S
T
M
1
〜
BASIC SYSTEM DYLAN 3000W 220V
WINDLASS
MOTOR
220V CA Max
5,5KW
TERMINAL BOARD
THREE-PHASE CONNECTION DIAGRAM
SENSOR
WATERTIGHT
HAND HELD
CHAIN-COUNTER
MOD. CHC1102 M
WATERTIGHT PANEL
CHAIN-COUNTER
MOD. CHC1202 M
-
+
DOWN UP BLUE BROWN BLACK BLUE BROWN BLACK
DOWN SENSOR UP
-
+
CAN H CAN L
GREY RED GREEN BROWN WHITE BLUE BLACK
BLUE BROWN BLACK
150
CAN H CAN L CAN H CAN L
BATTERY 24V
MULTI-PURPOSE
WATERTIGH HAND HELD
REMOTE CONTROL
MOD. HRC1002
RADIO RECEIVER RRC
MOD. R02 (2CH)
WINDLASS
CONTROL BOARD
MOD. 800
MOD. 900/D
DOWN
FOOT SWITCH
MOD. 900/U
UP
