OPERATING - MAINTENANCE
GB
MAINTENANCE
The battery charger does not need any maintenance. To ensure optimum performance from the
equipment, once a year check the cables and the electrical connections.
CONTROL PANEL
The control panel is made-up of three LEDS:
POWER LED, FLOAT LED and CHARGE LED (BULK, ABSORPTION, see fig.4)
The information supplied by the LEDS are listed below:
POWER LED
FLOAT LED
LED Color
No indication
FLOAT phase - FLOAT charge
Short circuit or overload in output.
Check output cables, the group of batteries and the points of use connected to the battery charger.
LED Status Description
LED Color
Off
No mains power or overheating.
In case of overheating check if the installation of the battery charger is correct.
Switch off and allow the equipment to cool down for at least 10 minutes.
Power ON
Green
Description
Off
Green
Green
Off
Fixed
Flashing
CHARGE LED (BULK, ABSORPTION)
LED Color
No indication
ABSORPTION phase or BULK phase
Short circuit or overload in output.
Check output cables, the group of batteries and the points of use connected to the battery charger.
LED Status Description
Off
Yellow
Yellow
Off
Fixed
Flashing
