SALSA M
2
Mini 71
Rev.1.0
Model: Quickie Salsa M
2
Mini
14.0 Specification sheets (EN 12184 & ISO 7176-15)
Sunrise Medical
Thorns Road
Brierley Hill
West Midlands
DY5 2LD
Phone: 0845 605 66 88
www.SunriseMedical.co.uk
Operating temperature: - 25°C to 50°C
Storage temperature: -40°C to 65°C
Moisture resistance: IPx4
No restrictions on humidity and air pressure
ISO 7176-15 Min Max Comments
Overall length (with legrest) - 112cm With Uni type hangers
Overall width powerbase - 52cm
Overall width seat 53cm 63cm Across std armpads
Folded length N.A N.A Not a folding wheelchair
Folded height N.A N.A Not a folding wheelchair
Total mass (w/batteries) 97kg 112kg Basic / With 30º tilt
Mass of the heaviest part 69kg 84kg Removable parts taken off
Static stability downhill 11º - Power tilt – 0º
Recline – 0º
FSH - 47cm
Seat – 16”/40cm
Static stability uphill 9º - Power tilt – 30º
Recline – 16º
FSH - 47cm
Seat – 20”/50cm
Static stability sideways 10º - Power tilt – 30º
Recline – 16º
FSH - 47cm
Seat – 20”/50cm
Energy consumption (Max. range) - 23 km
Dynamic stability uphill 6º 8º Depending on options
Obstacle climbing 5cm 7cm No-run / 0.5m run
Maximum speed forward 3.2km/h (2mph) 6.4 km/h (4mph) Dep. Programming option
Minimum braking distance from max. speed - 1.2m
Seat plane angle -5º 30º Depends on option
Effective seat depth 41cm 51cm 2.5cm increments
Effective seat width 41cm 51cm 2.5cm increments
Seat surface height at front edge 43cm 49mm Depends on option
Backrest angle -5° 30º Depends on option
Backrest height 46cm 51cm
Footrest to seat distance 36cm 51cm With Uni type hangers
Leg to seat surface angle - 84º With Uni type hangers
Armrest to seat distance 23cm 31cm
Front location of armrest structure 37cm 47cm
Minimum turning radius - 70cm With Uni type hangers
Mass of the test dummy - 140kg
EN 12184 Min Max Comments
Maximum height of kerb safely descend - 70mm
Minimum width of corridor - 1140mm With Uni type hangers
Minimum ground clearance 35mm -
Speed control operation force - 1,8 N
Direction control operation force - 1,5 N
Maximum occupant mass
(test dummy mass):
140 kg
The wheelchair Quickie
Salsa conforms to the
following standards:
a) requirements and
test methods for static,
impact and fatigue
strengths
(ISO 7176-8)
b) power and
control systems for
electric wheelchairs
requirements and test
methods (ISO 7176-14)
c) climatic test in
accordance with ISO
7176-9
d) requirements for
resistance to ignition in
accordance with
ISO 7176-16
e) the product is
specified as a Class B
power wheelchair, but
with limited range.
