The numbers (01.02.15.03.08.etc) in front of the system names refer to the
physical addresses assigned to the systems, not the sequence of the systems
to be arranged.
8). Select
Read Codes
from the
Select Function
menu and press the
Y
button.
If there are no Diagnostic Trouble Codes present, the display will indicate
NO CODES ARE STORED IN THE MODULE!
If there are any Diagnostic Trouble Codes present, the DTC number and its
definition will show On the LCD display.
The subcode, the communication protocol, the sequence of The DTC current-
ly being observed and the total number of codes detected will be observed
on the upper rig ht hand Corner of the display.
When a DTC's definition covers more than one display screen, use the
Y
button, as necessary,to view any additional information.
If the DTC definition is not available, an advisory message prompting you to
refer to the vehicle service manual will be observed on the display.
If more than one DTC is found,use the
UP/DOWN
scroll buttons, as neces-
sary,until all the codes have been shown up.
16627 --100 01/10
CAN BUS
======================
Solenoid Valve(A)
For Boost Pressure
Control(N75) :
Malfunction: P0243
Select Function
=======================
1) Read Codes
2) Erase Codes
3) ECU Information
4) Readiness Test
To Next Page
