2.Product Information
2.1 Tool Description
7
3
4
6
1
2
5
1. LCD DISPLAY
--—Indicates test results. Backlit, 128 X 64 pixel display
with contrast adjustment.
2. "Y" BUTTON
-- Confirms a selection (or action) from a menu. When a
DTCs definition covers more than one screen.it is used to move down to the
next screen for additional data.
3. "N" BUTTON
-- Cancels a selection (or action)from a menu or returns to
the menu.It is also used to set up the unit when being pressed and held for at
least 3 seconds.
