CHECK
OWNER S MANUAL
,
OBD2 CODE SCANNER
15
"
Pass
" --- Indicates that a particular monitor being checked has not compl-
eted its diagnostic testing.
"
Fail
" --- Indicates that a particular monitor being checked has not comple-
ted its diagnostic testing or the monitor is not supported on that vehicle.
3). Use the
UP/DOWN
scroll buttons to select Readiness Test from the
Select Function
menu and press the
Y
button.
If the Scan tool is not connected yet, then refer to Reading Codes from 1 to
7 at Paragraph 3.1.
4). Use the
UP/DOWN
scroll buttons, as necessary, to view the status of the
following monitors:
EGR Sys --- EGR System Monitor
O2 Sensor(s) --- O2 Sensors Monitor
Catalyst --- Catalyst Monitor
EVAP Sys --- Evaporative System Monitor
Heated O2 --- O2 Sensor Heater Monitor
Sec Air Inject --- Secondary Air Monitor
A/C --- A/C system Monitor
Catalytic Conv. --- Catalytic Convertor Monitor
Select Function
=======================
1) Read Codes
2) Erase Codes
3) ECU Information
4) Readiness Test
Readiness Test
=======================
EGR Sys Pass
Heated O2 Pass
O2 Sensor(s) Pass
A/C Pass
Sec.Air Inject Pass
EVAP Sys Fail
3). Press the
N
button to return to previous menu.
