If there are no Diagnostic Trouble Codes present, the display will indicate
NO CODES ARE STORED IN THE MODULE!
”
If there are any Diagnostic Trouble Codes present, the Fault Codes and
Pending Codes will be reported on the display.
OBDII/EOBD Diag.
========================
1) Read Codes
2) Erase Codes
9). Use the
UP/DOWN
scroll buttons to select
Read Codes
from the menu
and press the
Y
button.
The DTC number will appear on the upper left hand corner and its definition
will show Oil the body of screen.
The type of code (Generic or Manufacturer specific), the vehicle protocol,
the sequence of the DTC currently being observed. The total number of codes
detected and the module ID will be observed on the upper rig ht hand corner
of the Display.
If the code being displayed is a pending code the
Pd
icon will be observed
next to the DTC number on the upper rig ht hand corner of the display.
When a DTC's definition covers more than one display screen use the
Y
button,as necessarY, to view any additional information.
If the retrieved DTCs contain any manufacturer specific or enhanced codes
you will be prompted to refer to the CD DTC library or the vehicle service
manual to view the DTC definitions.
P0118 Pd 06/06
ISO9141 $09
======================
Pressure Control
Solenoid A Control
Circuit Low
To Next Page
