Connect tubes MF6-4 & MF6-5 to parts MF-5 & MF-7
BRACE TO GOAL FRAME
STEP I
MF6-4
MF6-5
MF6-4
MF6-5
MF-7
MF-7
MF-5
MF-5
DETAIL VIEW
DETAIL VIEW
MF-5
MF6-4
MF-7
MF6-5
